What’s Stainless Steel Passivation?

As one of the most extensively applied metal materials in such fields as building, chemical industry, food, and health, stainless steel is highly favored because of its excellent resistance to corrosion and aesthetic appeal. However, in practical use, the surface of stainless steel may be affected by environmental factors such as oxidation and corrosion, which can shorten its service life and affect its performance. A technology to further improve the anticorrosion property and appearance of stainless steel has been developed called surface passivation. This article will discuss in detail the process, principles, advantages, and precautions of stainless steel surface passivation.

What Is Passivation of Stainless Steel?

Corrosion in stainless steel is a chemical process whereby the reaction of iron with oxygen forms a layer of iron oxide, which leads to material degradation. Other environmental factors that can exacerbate this problem include hot and humid atmospheres, coastal areas, or industrial zones. This corrosion process results in a decline in mechanical and physical properties, weakening the steel and causing gradual structural deterioration.

In stainless steel, the development of the passive layer occurs through the action of chromium in the steel with oxygen either from the air or from water, creating a thin protective layer. This layer protects the surface of the stainless steel from oxidation and thus from future corrosion.

Why passivate stainless steel?

Stainless steel is widely recognized for its corrosion-resistant performance and finds broad applications across many industries, from kitchenware to construction, medical devices, and equipment for chemical processes. However, even stainless steel may be corroded under specific environmental and operating conditions. To further develop the corrosion resistance of such material, prolong its operation time, and ensure safety, stainless steel often passes a surface treatment called “passivation.”

Improving Corrosion Resistance

The corrosion resistance of stainless steel is provided by a thin, stable oxide film on its surface, protecting it from corrosive agents like water, oxygen, and acids. Nonetheless, processes such as welding and cutting can damage this layer or alter it irregularly, thus increasing corrosion susceptibility. Passivation restores a dense, uniform oxide film, thereby improving effectively the corrosion resistance and strength the material will have. Moreover,

Removing Potential Contaminants

In the course of manufacturing and processing, stainless steel tends to accumulate metal particles, oil residues, welding slag, and other contaminants on its surface. Such pollutants will not only affect the appearance and quality of stainless steel but also possibly release harmful substances during use, thus causing environmental pollution or health risks. Passivation as a pre-treatment step effectively removes these surface contaminants, ensuring the cleanliness and safety of the stainless steel.

Improvement of Luster and Appearance

Passivation will result in a smoother, even, and finely finished stainless steel surface that displays a specific metallic brilliance. Therefore, stainless steel products, apart from being beautifully and delicately processed, their service life could be much longer due to the prevention of dirt accumulation and that of corrosive agents on account of smoother surfaces.

Material Properties Enhancement

Besides providing improved corrosion resistance, the passivation treatment may also have additional beneficial effects on certain mechanical properties of stainless steel, such as in wear resistance. This is attributed to the oxide film formed during the process of passivation, increasing the lubricity of the metal surface and therefore making it tougher during application.

Meeting particular application requirements

Some applications, like medical appliances, food process machinery, and containers of chemicals, have extremely high requirements in regard to material resistance from corrosion and cleanliness. In these cases, the treatment of passivation is called for, which will make the stainless steel fit for usage according to requirements.

Stainless steel passivation process

Stainless steel surface passivation is done for the purpose of laying a uniform, compact oxide layer known as a passivation film on the surface of the stainless steel via chemical or electrochemical methods. This hugely amplifies the properties of the steel in corrosion and wear resistance, among others, without affecting its original metallic luster or appearance. Generally, the steps composing this passivation process include cleaning the surface, pickling, passivation, neutralization, rinsing, and air drying.

Surface Cleaning

Surface cleaning is the first of the necessary steps in this process of passivation, aiming to remove grease, dust, oxides, and other contaminants on the surface of the steel. The methods used for cleaning include washing with detergents and water and ultrasonic cleaning, an efficient and widely used approach in depth cleaning of surfaces in stainless steel.

Pickling Treatment

Pickling treatment involves the immersion of stainless steel in an acid solution-such as hydrochloric or nitric acid, suitably diluted-to remove oxides and contaminants. The acid reacts with oxides to form soluble salts, which assist in the elimination of pollutants. This treatment also roughens the surface to facilitate the formation of the passivation film. The concentration of acid and time must be carefully controlled to avoid excessive corrosion.

Neutralization Treatment

Immediately after pickling, residual acidic substances stay on the surface of the stainless steel and could start further corrosion. This is why neutralization is needed to offset those acidic leftovers. To achieve this, the surface is dipped in a basic solution like sodium hydroxide in order to neutralize those acids. Subsequently, rinsing is carefully done to ensure all residual chemicals are washed away from the surface, in preparation for passivation.

Passivation Treatment

Passivation treatment uses a specialized agent to form a dense oxide layer on the stainless steel surface. The agent, applied through immersion or spraying, reacts chemically with the surface, enhancing corrosion and wear resistance. Common passivating agents include sodium nitrate and chromium sulfate. The concentration and treatment time must be carefully controlled to achieve optimal results and avoid negative effects.

Rinsing and Drying

After passivation, the stainless steel surface must be rinsed with clean water to remove remaining passivation agent and pickling solution. Then, the surface should be dried by air or hot air to eliminate water spots. The result is a homogeneous, dense passivation film that greatly enhances both corrosion resistance and appearance for the stainless steel.

3 Methods And Techniques In Stainless Steel Passivation

Passivation of stainless steel improves corrosion resistance due to the formation of a protective layer of oxide on the surface. Many techniques are used based on application and the surrounding environmental conditions. Here are three of the widely used techniques: nitric acid passivation, citric acid passivation, and a combination of nitric acid with sodium dichromate.

Nitric Acid Passivation

Nitric acid passivation is one of the most common methods, involving immersion of stainless steel in a nitric acid solution, typically 20-30%, to remove free iron and surface contaminants. This treatment favors the formation of a chromium oxide layer, enhancing the material’s resistance to oxidation and corrosion significantly. It is especially effective for industries dealing with food processing, medical devices, and aerospace, where high corrosion resistance is critical. However, the process requires proper handling owing to the corrosive nature of nitric acid.

Citric Acid Passivation

Citric acid passivation is an environmentally benign alternative to nitric acid, where a solution of citric acid is used to treat stainless steel. This is safer for both the operators and the environment since citric acid is non-toxic and biodegradable. Although it takes longer to produce the same effect as nitric acid treatment, citric acid has proved effective in removing contaminants and enhancing the growth of the chromium oxide layer for protection. It is a better method for those industries that want to go green, such as pharmaceuticals and food production.

Nitric Acid plus Sodium Dichromate

For more demanding applications, passivation is done with a combination of nitric acid and sodium dichromate. The former provides better corrosion resistance under extreme conditions, especially those related to marine or industrial settings. Sodium dichromate acts in synergy with the nitric acid to eliminate contamination by iron and enhance the protective oxide layer. However, because of the toxicity associated with sodium dichromate, this process is subject to high safety standards and has application in high-performance industries, like aerospace and automotive.

Benefits Of Stainless Steel Passivation

Stainless steel passivation offers major advantages by enhancing the material’s resistance to corrosion. The process forms a dense oxide layer on the surface, preventing corrosive agents from reaching the steel substrate, thus improving the longevity and durability of stainless steel products. This makes passivated stainless steel ideal for use in harsh environments like chemical processing, marine applications, and medical equipment. By increasing corrosion resistance, passivation extends the service life of stainless steel parts, which reduces frequency in maintenance and replacements, translating to cost savings over time.

Besides, passivated stainless steel remains aesthetically appealing through the prevention of discoloration and tarnishing effects. The protective oxide layer ensures that the steel retains its original sheen, even in extreme environments. Moreover, passivation enables stainless steel to meet national requirements for standards such as the blue point test, therefore guaranteeing compliance and reliability. Basically, besides increasing performance, passivation reduces maintenance expenses and enhances the long-term value of stainless steel items.

What to Watch for with Passivation of Metal

Since it is the demand of machining processes that oil, wax, rust, and weld spatter should be removed, because stainless steel passivation demands the base material to be exposed; therefore, the part’s surface should be cleaned without oil, wax, rust, weld spatter, etc. Before passivation treatment, procedures such as oil removal, wax removal, rust removal, and weld spatter removal have to be done, followed by the rinsing of parts using flowing water before soaking them in the passivation tank.

For the salt spray test requirements, activation is required. For some stainless steel products, like auto parts, refrigeration parts, camera precision parts, and marine machinery, there is an extremely high demand for salt spray resistance, generally lasting thousands of hours in neutral salt spray testing. It is not appropriate to directly passivate them. The base material should be activated; for example, acid pickling can be used for activation if color requirements are not strict.

According to composition, the parts should be washed thoroughly with water, without the inclusion of copper, iron ions, or chloride ions. Passivation should be thoroughly cleaned to avoid secondary corrosion. Besides, it effectively avoids the contamination or weakened effect of passivation solution in the subsequent process. The passivation solution, whether nitric acid-based or citric acid-based, must never be mixed with copper, iron, or similar products, neither stored in a chloride environment; otherwise, the passivation solution will get rapidly depleted and its effectiveness seriously affected.

As to pH values, neutralization is necessary. Following immersion in the stainless steel passivation solution, parts have to be thoroughly cleaned by water. In parts with threads, gaps, blind holes, or corners, it is difficult to remove residual liquid with just plain water. For such situations, a neutralization process such as soaking in a 1-3% sodium hydroxide or sodium carbonate solution for 1 minute and then 1-2 rinses with flowing water is recommended before proceeding with the drying process.

Brightness requires pure water rinsing. For some workpieces with a near-mirror finish-such as blades or stainless steel kitchen and bathroom products-cleanliness with ordinary tap water after passivation can easily result in yellow spots and watermarks on the surface. It is recommended to rinse the parts by 80°C hot water or pure water as the final step to resolve the problem.

Conclusion

The stainless steel surface passivation process is an important method for improving corrosion resistance and aesthetic appearance of stainless steel. Through such steps as surface cleaning, pickling treatment, and passivation, a uniform and compact oxide film is formed on the surface of stainless steel, which can effectively enhance the corrosion resistance and wear resistance of the material. In practical applications, strict control of process parameters is necessary, protection equipment should be put on, waste liquids should be properly treated, and secondary pollution must be avoided to ensure effectiveness and safety during the passivation treatment. As technology advances and the continuous improvement of the process, this passivation treatment has become more effective and reliable.

Final Thoughts

Stainless steel passivation is a process that enhances the corrosion resistance of stainless steel by removing free iron from the surface and creating a protective oxide layer. This treatment is crucial in industries such as aerospace, medical, and food processing, where high reliability and durability are required. In my 15 years of surface finishing serxice experience, I’ve seen how passivation significantly improves the lifespan of components exposed to harsh environments. For instance, in a recent aerospace project, our passivated stainless steel parts showed a marked increase in resistance to rust and corrosion, outperforming untreated parts in long-term tests. At Ultirapid, we specialize in offering high-quality passivation services tailored to meet your specific requirements, ensuring that your stainless steel parts maintain their integrity and performance over time.
